Hello everyone. I have some doubts and I hope someone can clarify them. My Yeti 2017, like every other Yeti, is almost entirely PQ35, apart from the MIB2 (Composition Media 5L0 035 200 D). The BCM is a 1K0 937 087 AR. The factory RLS is a 5K7 955 559 C and even trying various encodings the rain closing never worked. Replaced with 5K7 955 559 B but same result.
I know that to have this function I have to mount an RLHS, so I took a used 81D 955 547 and a 5Q0 955 547 (both without final letter) to do some experiments. Since my Yeti is entirely PQ35, obviously on BCM and 5F I don't have advanced functional settings relating to the light/rain/humidity sensor.
Do I have any chance to successfully activate this feature? If so, with which RLHS encoding?
Thanks to anyone who can help me.
My autoscan:
Tuesday, 18, March, 2025,10:50:21:33380
VCDS — Windows Based VAG/VAS Emulator Running on Windows 7 x64
VCDS Version: 25.3.0.4 (x64) HEX-NET2 CB: 0.4660.5
Data version: 20250311 DS365.0
www.Ross-Tech.com
VIN: TMBJC75L1HN715908 License Plate: NUOVA YETI MARZO 2025
Mileage: 145570km-90453mi Repair Order:
--------------------------------------------------------------------------------
--------------------------------------------------------------------------------
Chassis Type: 5L-SK35 (7N0)
Scan: 01 03 08 09 10 15 16 17 19 25 42 44 46 52 55 5F 61 62 72
VIN: TMBJC75L1HN715908 Mileage: 145570km-90453miles
01-Engine — Status: OK 0000
03-ABS Brakes — Status: OK 0000
04-Steering Angle — Status: OK 0000
08-Auto HVAC — Status: OK 0000
09-Cent. Elect. — Status: OK 0000
10-Park/Steer Assist — Status: OK 0000
15-Airbags — Status: OK 0000
16-Steering wheel — Status: OK 0000
17-Instruments — Status: OK 0000
19-CAN Gateway — Status: OK 0000
25-Immobilizer — Status: OK 0000
42-Door Elect, Driver — Status: OK 0000
44-Steering Assist — Status: OK 0000
46-Central Conv. — Status: OK 0000
52-Door Elect, Pass. — Status: OK 0000
55-Headlight Range — Status: OK 0000
5F-Information Electr. — Status: OK 0000
61-Battery Regul. — Status: OK 0000
62-Door, Rear Left — Status: OK 0000
72-Door, Rear Right — Status: OK 0000
-------------------------------------------------------------------------------
Address 01: Engine (J623-DFSA) Labels:. 04L-907-309-V1.clb
Part No SW: 04L 906 016 HL HW: 04L 907 309 K
Component: R4 2.0l TDI H20 3228
Revision: 8AH20--- CVN: 5D372EB7B866C2AD
Coding: 02110012042401090000
Shop #: WSC 01286 386 08256
ASAM Dataset: EV_ECM20TDI01104L906016HL 004003
ROD: EV_ECM20TDI01104L906016HL_004.rod
VCID: FAA61F5B4C57FF9A413-80AE
VINID: 91D49A4C715C0587870452402009A06EB9
No fault code found.
Readiness: 0 0 0 0 X
-------------------------------------------------------------------------------
Address 03: ABS Brakes (J104) Labels:. User\1K0-907-379-60EC1-CC.lbl
Part No SW: 1K0 907 379 CC HW: 1K0 907 379 CC
Component: ESP MK60EC1 H46 0175
Revision: 00H46001
Coding: 913F200E092305FF891404E49021A052A1080021
Shop #: WSC 33361 790 00999
VCID: F5BC0C6765C990E22C1-80A0
No fault code found.
-------------------------------------------------------------------------------
Address 08: Auto HVAC (J255) Labels:| 5K0-907-044.clb
Part No SW: 3T0 907 044 CR HW: 3T0 907 044 CR
Component: Climatronic H19 0910
Revision: 00001010
Coding: 0010000003
Shop #: WSC 33361 790 00999
ASAM Dataset: EV_Climatronic A01010
ROD: EV_ClimaAutoBasis_SK35.rod
VCID: 845A61A33E93B96A2BF-80D0
No fault code found.
-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels:. User\1K0-937-08x-09.lbl
Part No SW: 1K0 937 087 AR HW: 1K0 937 087 AR
Component: BCM PQ35 H 112 0903
Revision: AC112903
Coding: 64000ABBE83326C4404800C0110089E04DF000AE50218128E400A7040041
Shop #: WSC 33361 790 00999
VCID: 815468B72101AC42009-80D4
Subsystem 1 — Part No: 5L1 955 119 B Labels: 1KX-955-119.CLB
Component: SK356 26 0610
Coding: 00F7B5
Subsystem 2 — Part No: 5K7 955 559 B Labels: USER\5K7-955-559.LBL
Component: RLS 241015 03 37 0059
Coding: 00005D
Subsystem 3 — Part No: 1K0 951 605 C
Component: LIN BACKUP HO H03 1301
No fault code found.
-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels:| 5J0-919-475.clb
Part No SW: 5J0 919 475 C HW: 5J0 919 475 A
Component: PARKHILFE 4K H11 0011
Revision: --H11--- Serial number: 32931720100823
Coding: 308007
Shop #: WSC 33361 790 00999
ASAM Dataset: EV_EPHVA14SKxxx0000 002001
ROD: EV_EPHVA14SKxxx0000_002_SK35.rod
VCID: B53CCC6725C9D0E2EC1-80E0
No fault code found.
-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels:| 5K0-959-655.clb
Part No SW: 5C0 959 655 B HW: 5C0 959 655 B
Component: AirbagVW10 014 0613
Serial number: 003G5RAXPLCN Dataset Number: 5L0003t____ 0160
Coding: 00004E31
Shop #: WSC 73430 790 00999
ASAM Dataset: EV_AirbaVW10SMEVW360 A01014
ROD: EV_AirbaVW10SMEVW360_SK35.rod
VCID: B134F877D1A1FCC2B09-80E4
Crash sensor for side airbag: driver side:
Subsystem 1 — Part No SW: 5K0 959 354 HW: 5K0 959 354
Component: S.Sens.Fahr.V H02 ----
Serial number: 3572MSME30336D5DZZZ$
Crash sensor for side airbag: passenger side:
Subsystem 2 — Part No SW: 5K0 959 354 HW: 5K0 959 354
Component: S.Sens.Beif.V H02 ----
Serial number: 3582MSME7B0B6D5DZZZH
Rear Side Airbag Crash Sensor (on driver's side):
Subsystem 3 — Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Fahr.H H02 ----
Serial number: 3516KSME5D5D1D43ZZZ3
Passenger side rear thorax airbag crash sensor:
Subsystem 4 — Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Beif.H H02 ----
Serial number: 3526KSME69581D43ZZZ$
No fault code found.
-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels:| 5K0-953-569.clb
Part No SW: 5K0 953 521 FL HW: 5K0 953 569 BD
Component: LENKS.MODUL 018 0230
Revision: FF010042 Serial number: 20170712300097
Coding: 1082100000
Shop #: WSC 33361 790 00999
ASAM Dataset: EV_SMLSNGVOLWSR8C 001001
ROD: EV_SMLSNGVOLWSR8C_SK35.rod
VCID: FBA81A5F436DC6925A5-80AE
Multifunction steering wheel control module:
Subsystem 1 — Part No SW: 5E0 919 719 L HW: 5E0 919 719 L
Component: E221__MFL-PR6 H02 0160
Serial number: 000000000A0147080617
Coding: 820000
No fault code found.
-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels:| 5K0-920-xxx-17.clb-SRI1
Part No SW: 5L0 920 840 T HW: 5L0 920 840 T
Component: KOMBI H03 1028
Serial number: 00000000000000
Coding: 120C230100
Shop #: WSC 33361 790 00999
ASAM Dataset: EV_Kombi_UDS_VDD_RM09 A05730
ROD: EV_Kombi_UDS_VDD_RM09_005_SK35.rod
VCID: BC2AD94306E301AA13F-80E8
No fault code found.
-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels:. 7N0-907-530-V2.clb
Part No SW: 7N0 907 530 BJ HW: 7N0 907 530 AL
Component: J533 Gateway H58 1682
Revision: H58 Serial number: 220717F1001115
Coding: 356322
Shop #: WSC 33361 790 00999
VCID: F9A4005749D1F482489-80AC
No fault code found.
-------------------------------------------------------------------------------
Address 25: Immobilizer (J334) Labels:| 5K0-920-xxx-25.clb
Part No SW: 5K0 953 234 HW: 5K0 953 234
Component: IMMO H03 1028
Serial number: 00000000000000
Coding: 000000
Shop #: WSC 33361 790 00999
ASAM Dataset: EV_Immo_UDS_VDD_RM09 A03710
ROD: EV_Immo_UDS_VDD_RM09_SK35.rod
VCID: EA862F1B3CF74F1AB13-80BE
No fault code found.
-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels:. 7N0-959-793.clb
Part No SW: 7N0 959 793 H HW: 7N0 959 793 F
Component: TSG FA H05 0561
Revision: Serial number: 0000265230762
Coding: 011003208000231003
Shop #: WSC 33361 790 00999
VCID: C7C0B6AF4FA552728ED-8092
No fault code found.
-------------------------------------------------------------------------------
Address 44: Steering Assist Labels: 1K0-909-14x-GEN3.clb
Part No: 1K0 909 144 R
Component: EPS_ZFLS Kl. 69 3501
Revision: 00H22000
Shop #: WSC 33361 790 00999
VCID: B924C05705513482089-80EC
No fault code found.
-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels:. 7N0-959-792.clb
Part No SW: 7N0 959 792 H HW: 7N0 959 792 F
Component: TSG BF H05 0561
Revision: Serial number: 0000265241502
Coding: 011001208C00231003
Shop #: WSC 33361 790 00999
VCID: C6DEBBAB48AF4B7A75B-8092
No fault code found.
-------------------------------------------------------------------------------
Address 55: Headlight Range (J745) Labels:. 5M0-907-357-V3.clb
Part No SW: 5M0 907 357 F HW: 7L6 907 357 C
Component: AFS-ECU H05 0111
Revision: -------- Serial number: -------------- Dataset Number: 5L0036t____ 0007
Coding: 03D2000033000000
Shop #: WSC 73430 790 00999
ASAM Dataset: EV_HeadlRegulVWAFSPt 002016
ROD: EV_HeadlRegulVWAFSPt_SK35.rod
VCID: B720C66F3FC522F2FED-80E2
Left_headlamp_power_output_stage:
Subsystem 1 — Part No: 1T0 941 329 B Labels: 3D0-941-329.CLB
Right_headlamp_power_output_stage:
Subsystem 2 — Part No: 1T0 941 329 B Labels: 3D0-941-329.CLB
No fault code found.
-------------------------------------------------------------------------------
Address 5F: Information Electr. (J794) Labels:| 3V0-035-MIB-STD2.clb
Part No SW: 5L0 035 200 D HW: 5L0 035 200 D
Component: MU-S--ER H32 0363
Serial number: SKZAZ2T5303494 Dataset Number: V03935245GW 0001
Coding: 03130600FF0000005111000000080A002F0107D40130010002
Shop #: WSC 77870 010 10848
ASAM Dataset: EV_MUStd4CTSAT 001022
ROD: EV_MUStd4CTSAT_SK35.rod
VCID: 9F100ECFB7357AB216D-80CA
No fault code found.
-------------------------------------------------------------------------------
Address 61: Battery Regul. (J840) Labels:. 1K0-907-534.clb
Part No SW: 7N0 907 534 HW: 7N0 907 530 AL
Component: Batt.regelung H58 1682
Serial number: 220717F1001115
Coding: 030F7873
Shop #: WSC 33361 790 00999
VCID: F1B4387711A1BCC2F09-80A4
Subsystem 1 — Part No SW: 1K0 915 181 L HW: 1K0 915 181 L
Component: J367-BDM H07 0270
Serial number: 34199C57225831574808
No fault code found.
-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388) Labels:. 7N0-959-795.clb
Part No SW: 7N0 959 795 F HW: 7N0 959 795 E
Component: TSG HL H05 0561
Revision: Serial number: 0000268809539
Coding: 010001200000531003
Shop #: WSC 33361 790 00999
VCID: C7C0B6AF4FA552728ED-8092
No fault code found.
-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389) Labels:. 7N0-959-795.clb
Part No SW: 7N0 959 795 F HW: 7N0 959 795 E
Component: TSG HR H05 0561
Revision: Serial number: 0000268812631
Coding: 010001200000531003
Shop #: WSC 33361 790 00999
VCID: C7C0B6AF4FA552728ED-8092
No fault code found.
End----------(Elapsed Time: 01:31, VBatt start/end: 12.2V/12.0V)-----------
-------------------------------1 Fault Found-------------------------------
Comments 17
One more info: in reality, by modifying the LIN BUS protocol, the BCM PQ35 — at least those produced from about 2015 onwards — also correctly detect the RLHS with spare part code 5Q0 955 547 x and 81D 955 547 x. The unpleasant aspect, however, is that the windshield wiper motor electronics are no longer detected… 🤣
For further information I add that my BCM does not even detect the sensor with spare part code 5Q0 955 547. At this point I have to think that there is no light/rain/humidity sensor compatible with Yeti 2017 PQ35 platform.😌
Yesterday I tried to connect the sensor 81D 955 547 A but it is not even recognized. I have my last hope with the sensor 5Q0 955 547 which should arrive tomorrow.
At this point I am forced to think that there is no Yeti Facelift (from 2014 onwards) that has a working rain closing. Obviously I would be very happy if someone could prove to me that this is not true.
Another one www.drive2.ru/l/4899916394579325971
Thank you very much for your contribution, unfortunately I already know all this information, but in my case it is not useful. My BCM 1K0 937 087 AR is the latest for PQ35 platform and my module 5F is 5L0 035 200 D, then not have the following adaptation channels:
(15)-Access control 2-Regenschliessen_ein_aus, значение "active"
(16)-Access control 2-Regenschliessen_art, значение "Permanent"
(28)-Access control 2-Menuesteuerung Regenschliessen, значение "active"
Good luck!
maurozagor
Thank you very much for your contribution, unfortunately I already know all this information, but in my case it is not useful. My BCM 1K0 937 087 AR is the latest for PQ35 platform and my module 5F is 5L0 035 200 D, then not have the following adaptation channels:
(15)-Access control 2-Regenschliessen_ein_aus, значение "active"
(16)-Access control 2-Regenschliessen_art, значение "Permanent"
(28)-Access control 2-Menuesteuerung Regenschliessen, значение "active"
Пользуйтесь ODIS . переключатель в положении Auto.
The light switch is obviously in the auto position. I don't see how ODIS could help me, since those three adaptation channels are not present in my 09 BCM controller. Thanks a lot anyway for your help
Некоторые адаптации VCDS не видит. Интереса ради я бы посмотрел при помощи ODIS.
Thanks again for your advice, I'll try it as soon as I can.
В положении авто не переключатель света, а режим работы дворников .
Если вы включили 6 бит 4 байта 9 блока, то должно сработать. Приоткройте окна, закройте авто. На лобовое стекло в зоне нахождения сенсора дождя, полейте воды . окна должны автоматически закрыться .
Вы же этого добиваетесь, если я правильно понимаю?!)
You understand perfectly, and I follow all these instructions to the letter, but it still doesn't work. Keep in mind that I have already successfully performed this upgrade on several models, both mine and other friends' (Golf 5, Golf 6, Yeti pre facelift, Golf 7, etc.)
One more — see point 5. 7) www.drive2.ru/l/553735497298478030
Obviously I have already activated this bit 6, and I have also activated bit 5
Кодировка
9 блок → кодирование → длинное кодирование → 4 Байт → 6 бит → включить
Maybe it helps: www.drive2.ru/l/5430025
Translate it into Russian, this is a Russian-language resource
Sorry, but I've already tried on other occasions with disastrous results. 😥
If anyone wants to answer, please do so in Russian, this way Google Translate works decently.
