LOG… знакомство с vag-com

нажал на кнопку автоскан. записал лог файл.

Tuesday, 03, December, 2013,17:39:23:32264
VCDS Version: Release 11.11.3
Data version: 20120401

--------------------------------------------------------------------------------
--------------------------------------------------------------------------------

Chassis Type: 7N0
Scan: 01 02 03 08 09 10 15 16 17 19 25 2E 42 44 46 52 56 62 72

VIN: VSSZZZ1PZCR063397

01-Engine — Status: Malfunction 0010
02-Auto Trans — Status: OK 0000
03-ABS Brakes — Status: Malfunction 0010
04-Steering Angle — Status: OK 0000
08-Auto HVAC — Status: OK 0000
09-Cent. Elect. — Status: Malfunction 0010
10-Park/Steer Assist — Status: OK 0000
15-Airbags — Status: OK 0000
16-Steering wheel — Status: OK 0000
17-Instruments — Status: OK 0000
19-CAN Gateway — Status: OK 0000
25-Immobilizer — Status: OK 0000
2E-Media Player 3 — Status: OK 0000
42-Door Elect, Driver — Status: OK 0000
44-Steering Assist — Status: Malfunction 0010
46-Central Conv. — Status: OK 0000
52-Door Elect, Pass. — Status: OK 0000
56-Radio — Status: OK 0000
62-Door, Rear Left — Status: OK 0000
72-Door, Rear Right — Status: OK 0000

-------------------------------------------------------------------------------
Address 01: Engine (CDA) Labels: 06J-907-115-CDA.clb
Part No SW: 1P0 907 115 AE HW: 1P0 907 115 Q
Component: 1.8l R4/4V TFSI 0040
Revision: AAH18--- Serial number:
Coding: 0303000C24070160
Shop #: WSC 06402 785 00200
VCID: 6ED9D061798C249

2 Faults Found:
001674 — ECM Power Relay Load Circuit: (J271)
P068A — 000 — De-Energized Performance Too Early — Intermittent
Freeze Frame:
Fault Status: 00100000
Fault Priority: 0
Fault Frequency: 2
Mileage: 0 km
Time Indication: 0

Freeze Frame:
RPM: 0 /min
Load: 0.0 %
Speed: 0.0 km/h
Temperature: -2.0°C
Temperature: 0.0°C
Absolute Pres.: 0.0 mbar
Voltage: 0.000 V

005708 — Oil Pressure Switch for reduced Oil Pressure
P164C — 000 — Implausible Signal — Intermittent
Freeze Frame:
Fault Status: 00100000
Fault Priority: 0
Fault Frequency: 2
Mileage: 18 km
Time Indication: 0
Date: 2007.14.01
Time: 07:24:42

Freeze Frame:
RPM: 0 /min
Load: 0.0 %
Speed: 0.0 km/h
Temperature: 0.0°C
Temperature: 3.0°C
Absolute Pres.: 1000.0 mbar
Voltage: 11.684 V

Readiness: 0000 0000

-------------------------------------------------------------------------------
Address 02: Auto Trans Labels: 0AM-300-04x.lbl
Part No SW: 0AM 300 053 A HW: 0AM 927 769 D
Component: GSG DSG AG7 431 3070
Revision: 00043014 Serial number: CU501203025457
Coding: 0000020
Shop #: WSC 06402 785 00200
VCID: 2A511C7185E4089

No fault code found.

-------------------------------------------------------------------------------
Address 03: ABS Brakes (J104) Labels: 1K0-907-379-60EC1F.clb
Part No SW: 1K0 907 379 BJ HW: 1K0 907 379 BJ
Component: ESP MK60EC1 H31 0121
Revision: 00H31001
Coding: 113B4012092800FD880E02ED90200041350800
Shop #: WSC 04941 000 00000
VCID: 7BFFE935FAFE411

1 Fault Found:
00668 — Supply Voltage Terminal 30
001 — Upper Limit Exceeded — Intermittent
Freeze Frame:
Fault Status: 00100001
Fault Priority: 1
Fault Frequency: 1
Reset counter: 41
Mileage: 15 km
Time Indication: 0
Date: 2005.14.29
Time: 00:00:01

Freeze Frame:
Count: 16387
Count: 12
Count: 29184
Count: 129
Count: 41216
Count: 0
Count: 255
Count: 11264

-------------------------------------------------------------------------------
Address 08: Auto HVAC (J255) Labels: 5K0-907-044.clb
Part No SW: 5P0 907 044 S HW: 5P0 907 044 S
Component: Climatronic H18 0804
Revision: 00001001
Coding: 0000000002
Shop #: WSC 06402 785 00200
ASAM Dataset: EV_Climatronic A01010
ROD: EV_Climatronic_SE35.rod
VCID: 40855ED9DB98E29

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels: 1K0-937-08x-09.clb
Part No SW: 5K0 937 086 M HW: 5K0 937 086 M
Component: BCM PQ35 M 021 0064
Revision: BC021001
Coding: 40180A3E80250CC04280008095008104425100A8727D8D605C8040000040
Shop #: WSC 04941 000 00000
VCID: 3E792021A96C949

Subsystem 1 — Part No: 1P0 955 119 D
Component: Wischer 21031 26 0611
Coding: 00DB90

Subsystem 2 — Part No SW: 1P0 955 559 A HW: 1P0 955 559 A
Component: REGENLICHTSEN H04 0003
Coding: 02542E

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels: 3C8-919-475.clb
Part No SW: 5P0 919 475 B HW: 8P0 919 475 M
Component: PARKHILFE 4K H08 0008
Revision: -------- Serial number: 36861207702344
Coding: 000101
Shop #: WSC 04941 000 00000
VCID: 3A712C31B544B89

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags Labels: 5N0-959-655.lbl
Part No SW: 5N0 959 655 AA HW: 5N0 959 655 AA
Component: J234__A0A VW10 HI 2118
Revision: 24017000 Serial number: 003L7P4VXVC
Coding: 0012353
Shop #: WSC 06402 785 00200
VCID: 7CFDEA293FF0469

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels: 5K0-953-569.clb
Part No SW: 5K0 953 521 AT HW: 5K0 953 569 B
Component: LENKS.MODUL 014 0140
Revision: FF010040 Serial number: 20120319302074
Coding: 1892140002
Shop #: WSC 06402 785 00200
ASAM Dataset: EV_SMLSNGVOLWSXS A01004
ROD: EV_SMLSNGVOLWSXS_SE35.rod
VCID: 7EF9E021E1EC549

Multifunction steering wheel control module:
Subsystem 1 — Part No SW: 1P0 959 538 A HW: 1P0 959 538 A
Component: E221__MFL-TAP H02 0102
Coding: E30000

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels: None
Part No SW: 1P0 920 811 B HW: 1P0 920 811 B
Component: KOMBI H05 0605
Serial number: 00000000000000
Coding: 110B01
Shop #: WSC 131071 1023 2097151
ASAM Dataset: EV_Kombi_UDS_VDD_RM09 A04113
ROD: EV_Kombi_UDS_VDD_RM09_SE35.rod
VCID: 2855E67953E83A9

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels: 7N0-907-530-V2.clb
Part No SW: 7N0 907 530 M HW: 1K0 907 951
Component: J533 Gateway H42 1623
Revision: H42 Serial number: 090312F1003644
Coding: 350202
Shop #: WSC 04941 000 00000
VCID: 3A712C31B544B89

No fault code found.

----------------------------------------------------------------------------

-------------------------------------------------------------------------------
Address 2E: Media Player 3 (J650) Labels: 5N0-035-342.lbl
Part No SW: 5N0 035 342 E HW: 5N0 035 342 E
Component: SG EXT.PLAYER H13 0240
Revision: A1001003 Serial number: 7662149441
Coding: 010000
Shop #: WSC 04941 000 00000
VCID: 2953E37D40E2031

No fault code found.

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels: 3C0-959-70X-GEN4.clb
Part No SW: 3C8 959 701 HW: 3C0 959 793 C
Component: TUER-SG FT 002 0507
Revision: 12110009 Serial number: 0004495919
Coding: 0010B0
Shop #: WSC 06402 785 00200
ASAM Dataset: EV_TSGFPQ35BRFVW46X A04001
ROD: EV_TSGFPQ35BRFVW46X.rod
VCID: EDDB576D3C8A5F1

Slave Driver:
Subsystem 1 — Part No SW: 3C0 959 703 E HW: 3C0 959 795 E
Component: J388__TSG-HL 008 1501
Serial number: 00000006545815
Coding: 000090

No fault code found.

-------------------------------------------------------------------------------
Address 44: Steering Assist Labels: 1Kx-909-14x-44.clb
Part No: 1K0 909 144 P
Component: EPS_ZFLS Kl. 65 3305
Revision: 00H22000
Shop #: WSC 06402 785 00200
VCID: 377735054656A51

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels: 3C0-959-70X-GEN4.clb
Part No SW: 3C8 959 702 HW: 3C0 959 792 C
Component: TUER-SG BT 002 0507
Revision: 14110009 Serial number: 0004473370
Coding: 0010B0
Shop #: WSC 06402 785 00200
ASAM Dataset: EV_TSGBPQ35BRFVW46X A04001
ROD: EV_TSGBPQ35BRFVW46X_SE35.rod
VCID: EED95061318CA49

Slave Passenger:
Subsystem 1 — Part No SW: 3C0 959 704 E HW: 3C0 959 794 E
Component: J389__TSG-HR 008 1501
Serial number: 00000006525729
Coding: 000090

No fault code found.

-------------------------------------------------------------------------------
Address 56: Radio (J503) Labels: 5M0-035-1xx-56.clb
Part No SW: 5P0 035 186 B HW: 5P0 035 186 B
Component: Media2.0 003 0082
Revision: 01000001 Serial number: SEZ1Z3M5053369
Coding: 01060400040000
Shop #: WSC 04941 000 00000
VCID: 2E591061790C649

No fault code found.

End ---------------------------------------------------------------------
